| № | Номер запчасти | Наименование | Кол-во | Срок поставки/дней | Цена | |
| 1 | 417222617 | Inner half assy | 1 | Узнать цены | ||
| 2 | 417222620 |
Outer half assy | includes items 2 thru 3 Bombardier |
1 | 45-55 дней | 24972 ₽ | |
| 3 | 417222758 |
Bushing outer half Bombardier |
1 | 45-55 дней | 1957 ₽ | |
| 4 | 413703100 |
Loctite 609 10cc Bombardier |
1 | 45-55 дней | 2321 ₽ | |
| 5 | 417222671 |
Lever assy | includes items 5 thru 6 Bombardier |
1 | 45-55 дней | 3047 ₽ | |
| 6 | 417222633 |
Flanged bushing Bombardier |
1 | 45-55 дней | 499 ₽ | |
| 7 |
Roller assy - does not apply to this model Arctic Cat |
1 | 45-55 дней | 0 ₽ | ||
| 8 | 417004302 |
Thrust washer Bombardier |
1 | 45-55 дней | 1522 ₽ | |
| 9 | 417222717 | Pin | 1 | Узнать цены | ||
| 10 | 250400060 |
Cotter pin Bombardier |
1 | 45-55 дней | 179 ₽ | |
| 11 |
Nut - does not apply to this model Arctic Cat |
1 | 45-55 дней | 0 ₽ | ||
| 12 | 417223164 |
Lever axle Bombardier |
1 | 45-55 дней | 401 ₽ | |
| 13 | 413703100 |
Loctite 609, 10 ml Bombardier |
1 | 45-55 дней | 2321 ₽ | |
| 14 | 417222312 |
Spring seat Bombardier |
1 | 45-55 дней | 781 ₽ | |
| 15 | 417222204 | Spring, white/white | 1 | Узнать цены | ||
| 16 | 417007500 |
Spring cover assy | includes items 16 thru 17 Bombardier |
1 | 45-55 дней | 4353 ₽ | |
| 17 | 417009204 |
Bushing spring cover Bombardier |
1 | 45-55 дней | 1522 ₽ | |
| 18 | 205084044 |
Allen screw m6 x 40 Bombardier |
1 | 45-55 дней | 264 ₽ | |
| 19 | 250200009 |
Friction-washer Bombardier |
1 | 45-55 дней | 195 ₽ | |
| 20 | 233261414 |
Hex. flanged elastic nut m6 x 1.0 Bombardier |
1 | 45-55 дней | 123 ₽ | |
| 21 | 417222676 |
Ramp 427 Bombardier |
1 | 45-55 дней | 2465 ₽ | |
| 22 | 250400050 |
Spring pin m10 x 22 Bombardier |
1 | 45-55 дней | 266 ₽ | |
| 23 | 250000418 |
Flanged hex. screw m6 x 18, scotch grip Bombardier |
1 | 45-55 дней | 365 ₽ | |
| 24 | 417222955 |
Calibration screw Bombardier |
1 | 45-55 дней | 3119 ₽ | |
| 25 | 417005600 |
Washer Bombardier |
1 | 45-55 дней | 365 ₽ | |
| 26 | 233061414 |
Locking nut m6 Bombardier |
1 | 45-55 дней | 149 ₽ | |
| 27 | 417005700 |
Spring Bombardier |
1 | 45-55 дней | 439 ₽ | |
| 28 | 732401030 |
O-ring Bombardier |
1 | 45-55 дней | 90 ₽ | |
| 29 | 417223021 |
Slider shoe Bombardier |
1 | 45-55 дней | 663 ₽ | |
| 30 | 417009205 |
Protector Bombardier |
1 | 45-55 дней | 1595 ₽ | |
| 31 |
Circlip - does not apply to this model Arctic Cat |
1 | 45-55 дней | 0 ₽ | ||
| 32 | 20110 | Washer | 1 | Узнать цены | ||
| 33 | 417120000 |
Screw Bombardier |
1 | 45-55 дней | 6023 ₽ | |
| 34 | 417300572 |
Drive belt Bombardier |
1 | 45-55 дней | 22648 ₽ | |
| 35 | 250000412 |
Flanged hex. screw m6 x 12, scotch grip Bombardier |
1 | 45-55 дней | 365 ₽ | |
| 36 | 206260699 |
Weight Bombardier |
1 | 45-55 дней | 343 ₽ |
