| № | Номер запчасти | Наименование | Кол-во | Срок поставки/дней | Цена | |
| 1 | 17410-44D10 |
Case, water pump Suzuki Moto |
1 | 45-55 дней | 13099 ₽ | |
| 2 | 17415-14300 |
.bolt Suzuki Moto |
1 | 45-55 дней | 403 ₽ | |
| 3 | 09168-08016 |
.gasket Suzuki Moto |
1 | 45-55 дней | 221 ₽ | |
| 4 | 17435-12C00 |
O ring Suzuki Moto |
1 | 45-55 дней | 901 ₽ | |
| 5 | 17491-12C00 |
Impeller/shaft Suzuki Moto |
1 | 45-55 дней | 2804 ₽ | |
| 6 | 17470-02F00 |
Seal, mechanical Suzuki Moto |
1 | 45-55 дней | 3945 ₽ | |
| 7 | 09283-10005 |
Oil seal (10x20x5) Suzuki Moto |
1 | 45-55 дней | 625 ₽ | |
| 8 | 09100-06162 |
Bolt Suzuki Moto |
1 | 45-55 дней | 380 ₽ | |
| 9 | 09164-06006 |
Washer Suzuki Moto |
1 | 45-55 дней | 332 ₽ | |
| 10 | 09168-06025 |
Washer Suzuki Moto |
1 | 45-55 дней | 372 ₽ | |
| 11 | 01547-0620B |
Bolt Suzuki Moto |
2 | 45-55 дней | 326 ₽ | |
| 12 | 01547-0665B |
Bolt Suzuki Moto |
1 | 45-55 дней | 428 ₽ | |
| 13 | 17510-16702 |
Shaft, water pump Suzuki Moto |
1 | 45-55 дней | 14786 ₽ | |
| 14 | 17611-44D20 |
Joint, water pump drive Suzuki Moto |
1 | 45-55 дней | 4131 ₽ | |
| 15 | 09261-04009 |
Pin, driven gear Suzuki Moto |
1 | 45-55 дней | 192 ₽ |
