| № | Номер запчасти | Наименование | Кол-во | Срок поставки/дней | Цена | |
| 1 | 503189156 |
Pivot arm axle Bombardier |
1 | 45-55 дней | 2723 ₽ | |
| 2 | 503192440 |
Long bolt m8 Bombardier |
1 | 45-55 дней | 3836 ₽ | |
| 3 | 503189157 |
Washer Bombardier |
4 | 45-55 дней | 412 ₽ | |
| 4 | 233281414 |
Hex. flanged elastic nut m8 Bombardier |
1 | 45-55 дней | 173 ₽ | |
| 5 | 503192087 |
Rear arm Bombardier |
1 | 45-55 дней | 20375 ₽ | |
| 6 | 503191555 |
Swivel bushing Bombardier |
2 | 45-55 дней | 748 ₽ | |
| 7 | 503191178 |
Spring cam axe Bombardier |
1 | 45-55 дней | 3531 ₽ | |
| 8 | 503191191 |
Lh spring cam Bombardier |
1 | 45-55 дней | 1786 ₽ | |
| 9 | 503191190 |
Rh spring cam Bombardier |
1 | 45-55 дней | 1773 ₽ | |
| 10 | 205582544 |
Socket head screw m8 x 25, scotch grip Bombardier |
2 | 45-55 дней | 237 ₽ | |
| 11 | 503192095 |
Lower shaft Bombardier |
1 | 45-55 дней | 5958 ₽ | |
| 12 | 503191302 |
Pivot arm Bombardier |
1 | 45-55 дней | 15254 ₽ | |
| 13 | 503192320 | Block | 1 | Узнать цены | ||
| 14 | 250400005 |
Dowel pin 4 x 8 mm Bombardier |
2 | 45-55 дней | 153 ₽ | |
| 17 | 503189148 |
Washer Bombardier |
2 | 45-55 дней | 350 ₽ | |
| 18 | 205523587 |
Socket head screw scotch grip din.912 Bombardier |
2 | 45-55 дней | 263 ₽ | |
| 19 | 408200700 |
Grease fitting Bombardier |
2 | 45-55 дней | 427 ₽ | |
| 20 | 503191774 |
Washer Bombardier |
2 | 45-55 дней | 288 ₽ | |
| 21 | 503191773 |
Bushing Bombardier |
2 | 45-55 дней | 1786 ₽ | |
| 22 | 503191775 |
Bushing Bombardier |
2 | 45-55 дней | 2004 ₽ | |
| 23 | 503191776 |
Upper shaft Bombardier |
1 | 45-55 дней | 5958 ₽ | |
| 24 | 206260844 |
Socket set screw m6 x 8 Bombardier |
2 | 45-55 дней | 190 ₽ | |
| 24a | 293800060 |
Loctite 243, 10 ml Bombardier |
1 | 45-55 дней | 3230 ₽ | |
| 25 | 503191777 |
Black wheel ass'y, 144 mm includes 25 to 26 Bombardier |
2 | 45-55 дней | 4745 ₽ | |
| 26 | 503191778 |
Ball bearing Bombardier |
2 | 45-55 дней | 1506 ₽ | |
| 27 | 503191782 |
Retaining ring Bombardier |
2 | 45-55 дней | 1795 ₽ | |
| 28 | 503189276 |
Washer Bombardier |
2 | 45-55 дней | 412 ₽ | |
| 29 | 207226044 |
Hex. screw m12 x 60, scotch grip Bombardier |
1 | 45-55 дней | 2362 ₽ | |
| 30 | 503191615 |
Lh spring, square Bombardier |
1 | 45-55 дней | 7775 ₽ | |
| 31 | 503191614 |
Rh spring, square Bombardier |
1 | 45-55 дней | 7775 ₽ | |
| 32 | 503191345 |
Plastic bushing Bombardier |
1 | 45-55 дней | 906 ₽ | |
| 33 | 503191344 |
Spring axle Bombardier |
1 | 45-55 дней | 4440 ₽ | |
| 34 | 205582544 |
Socket head screw m8 x 25, scotch grip Bombardier |
2 | 45-55 дней | 237 ₽ | |
| 35 | 219700417 | Synthetic grease, 400 g | 1 | Узнать цены |
